Standard: Based on VDE 0812

Voltage Grade (Not for power installation): Max. 250 V

Test Voltage: Core/core 2000 V. Core/screen 1000 V

Insulation Resistance: Min. 5000 GΩ x cm

Mutual Capacitance* : Max. 60 nF/km

Characteristic Impedance*: 100 Ω ±15

Cross-talk Attenuation : Upto 1 MHz min. 50 dB. Upto 10 MHz min. 40 dB

Inductance: Approx. 0.65 mH/km

Temperature Range: Flexing -5°C to +70°C. Fixed installation -30°C to +70°C

Minimum Bending Radius : Flexing 15 x cable ø. Fixed installation 6 x cable ø
