Standard: UL 1015, 758, CSA C 22.2 No 210 & BS 6231

Nominal Voltage: 600V UL – Type AWM 105°C 600V CSA – Type AWM 105°C 600V BS 6231 CK type 90°C 600V / 1000 V

Test Voltage (Spark Test): AWG 18 to 16 : 6kV ≥ AWG 8: 7.5kV

Temperature Range: Flexing -5°C to +105°C. Fixed installation -20°C to +105°C

Bending Radius :

Cable diameter ≤ 8 mm: 4 x outer diameter

Approx diameter > 8 to 12 mm: 5 x outer diameter

Approx diameter > 12 mm: 6 x outer diameter
